Two-shaft shredder with two drives – SDT

Two-shaft shredder with two drives – SDT

Two-shaft shredder with two drives – SDT

SDT range two-shaft shredders are designed for applications with requiring longer life span, more power and reliability and less maintenance, such as in incinerators, waste sorting facilities, plastic recycling lines, processing of passenger car and lorry tyres, disposal of disused barrels, railroad sleepers, used car oil filters, etc. Depending on required application, the shredding rotor segments can be fitted with replaceable blades, which make maintenance cheaper and faster while saving expensive materials and, as a result, spare parts. The blades can be replaced without disassembling the machine. The resulting crushed material can be used as alternative fuel, for further processing or simply for decreasing waste volume, for cheaper and more environment-friendly transport (so as not to transport air).

 Shredders can be stationary or mobile with optional power generator for removal of dump sites in multiple areas. Shredders are equipped with automatic control system, which does not require too much attention from the operator. Control system actively monitors and controls overloads, set reverse counts and operational hours.

Technical data

Basic technical data
Work surfaceto 2300 x 1050 mm
Power inputto 2 x 75 kW
Outputto 10 000 kg/hour
Output fractionto 80 x 500 mm
Type Work surface
l x w (mm)
Input
kW
Output
kg/h
Output fraction
(mm)
Weight
(kg)
SDT 800 800 x 800 2 x 15 - 2 x 30 2 500 - 3 000 50 x 200 - 300 5 500
Type Work surface
l x w (mm)
Input
kW
Output
kg/h
Output fraction
(mm)
Weight
(kg)
SDT 1150 1 150 x 800 2 x 22 - 2 x 30 3 500 - 4 500 50 x 200 - 300 7 000
Type Work surface
l x w (mm)
Input
kW
Output
kg/h
Output fraction
(mm)
Weight
(kg)
SDT 1220 1 220 x 800 2 x 15 - 2 x 18,5 3 500 - 8 000 15 x 30 - 200 3 000
Type Work surface
l x w (mm)
Input
kW
Output
kg/h
Output fraction
(mm)
Weight
(kg)
SDT 1650 1 650 x 800 2 x 22 - 2 x 30 4 500 - 7 000 15 x 200 - 300 8 000
Type Work surface
l x w (mm)
Input
kW
Output
kg/h
Output fraction
(mm)
Weight
(kg)
SDT 1800 1 800 x 1 000 2 x 37 - 2 x 75 7 000 - 9 500 80 x 200 - 400 10 500
Type Work surface
l x w (mm)
Input
kW
Output
kg/h
Output fraction
(mm)
Weight
(kg)
SDT 2300 2 300 x 1 050 2 x 55 - 2 x 75 8 000 - 10 000 80 x 300 - 500 15 000

Industrial branches

agriculture

agriculture

automotive industry

automotive industry

construction industry

construction industry

electrical engineering

electrical engineering

food processing

food processing

chemical industry

chemical industry

power engineering

power engineering

rubber industry

rubber industry

transport and logistics

transport and logistics

waste processing

waste processing

woodworking

woodworking
